汪雪良, 顾学康, 胡嘉骏. 船体梁刚度对波激振动影响的比较研究[J]. 中国舰船研究, 2016, 11(5): 55-62,77. DOI: 10.3969/j.issn.1673-3185.2016.05.009
引用本文: 汪雪良, 顾学康, 胡嘉骏. 船体梁刚度对波激振动影响的比较研究[J]. 中国舰船研究, 2016, 11(5): 55-62,77. DOI: 10.3969/j.issn.1673-3185.2016.05.009
WANG Xueliang, GU Xuekang, HU Jiajun. Comparative study of the effect of hull-girder stiffness on springing behaviors[J]. Chinese Journal of Ship Research, 2016, 11(5): 55-62,77. DOI: 10.3969/j.issn.1673-3185.2016.05.009
Citation: WANG Xueliang, GU Xuekang, HU Jiajun. Comparative study of the effect of hull-girder stiffness on springing behaviors[J]. Chinese Journal of Ship Research, 2016, 11(5): 55-62,77. DOI: 10.3969/j.issn.1673-3185.2016.05.009

船体梁刚度对波激振动影响的比较研究

Comparative study of the effect of hull-girder stiffness on springing behaviors

  • 摘要: 船舶大型化发展的趋势使得其尺度越来越大,而结构轻量化设计的需求则使高强度钢被大量应用于其结构设计之中,相对于传统的小尺度船舶,相对刚度的下降使得船体梁变得越来越“软”,这将导致大型船舶在波浪中航行时船体结构波激振动特性发生变化。采用模型试验和理论预报的方法,研究某大型工程船在不同船体梁刚度下的低频和高频垂向波浪载荷响应。分段试验模型采用2种横剖面惯性矩的钢质梁,用以分别模拟船舶横剖面原始的和变化后的刚度。采用三维水弹性理论对该船在波浪中的响应进行预报,并与模型试验结果进行比较。结果显示:小刚度的船体梁更易在波浪中发生波激振动;频繁的波激振动将导致结构发生严重的疲劳损伤问题。这种刚度变化对船体梁波激振动的影响规律表明,有必要将刚度作为大型船舶结构优化设计的重要参数之一。



    Abstract: With the large scale development trend, the lengths of ships are constantly increasing. As a result, high strength steel is widely used due to the demand of lightweight design of ship structures. Hull girder of the ship, in particular, becomes much more flexible than those of small and medium-sized ships. This results in different characteristics of springing behaviors of ship structures when the ship travels on the sea. In this paper, a large engineering ship is taken as the research subject in order to study its low-and high-frequency wave induced load responses in waves. Two kinds of steel girders with different transverse-section moments of inertia are used to simulate original and changed stiffness in a segmented model. The 3D hydroelasticity theory is employed to predict responses of the ship in waves, and comparison analysis is also conducted between experimental and theoretical results. It is shown that springing behavior is prone to happen with low hull-girder stiffness, and continual springing behavior will result in serious fatigue damage to ship structures. The necessity of considering the hull-girder stiffness as an important parameter in the structural optimization design of large ships is thus verified as the effect of hull-girder stiffness on springing behaviors cannot be neglected.



/
