Effects of Changing the Explosive Position on the Damage of Stiffened Plates Subjected to Air Contact Explosion
-
摘要: 为研究爆点位置对导弹接触爆炸下船体板架破坏所造成的影响,通过有限元模拟研究加筋板架在由2种药量和4个爆点位置组合成的8种工况下的破坏过程、破口大小及变形能,对比分析同种药量下爆点位置对加筋板架破坏的影响。结果表明:相同药量的炸药在加筋板架的不同爆点位置接触爆炸时,所产生破口大小间的差异可达20%以上,药量较小时,破口形貌的差别也较大;炸药在肋骨与纵骨交汇处爆炸时,与相同炸药在板格中心爆炸相比,加强筋的变形能可高出2倍左右,加筋板架的变形能则可高出40%以上。Abstract: To investigate the effects of changing the explosive point on the missile air contact explosion damage(on stiffened plates),finite element simulations are conducted to analyze the damage processes, crevasse sizes and distortional energies of stiffened plates in eight different cases(a combination of two explosive charges and four explosive points). The results show that when the same amount of explosive explodes at different points,the discrepancy of crevasse sizes can go beyond 20%. Also,the crevasse shapes are markedly distinct even with less explosive charge. Particularly,when the explosion occurs at the decussation of stiffeners,the distortional energy can be twice as much as that at the centre,and the distortional energy of the whole plate can be 40% or more.
-
Key words:
- air blast /
- stiffened plate /
- numerical simulation /
- crevasse
-
NURICK G N,RADFORD A M. Deformation and tearing of clamped circular plates subjected to localized central blast load[C]//Recent Developments in Computational and Applied Mechanics. Barcelona,Spain,1997:276-301. WIERZBICKI T. Petaling of plates under explosive and impact loading[J]. International Journal of Impact Engineering,1999,22:935-954. JACOB N,YUEN C K,NURICK G N,et al. Scaling aspects of quadrangular plates subjected to localized blast loads-experiments and predictions[J]. International Journal of Impact Engineering,2004,30:1179-1208. 朱锡,白雪飞,张振华. 空中接触爆炸作用下船体板架塑性动力响应及破口研究[J]. 中国造船,2004,45(2):43-50.ZHU X,BAI X F,ZHANG Z H. Plastic dynamic response and crevasse research of ship panels subjected to air contact explosion[J]. Ship Building of China,2004,45(2):43-50. 张振华,朱锡. 刚塑性板在柱状炸药接触爆炸载荷作用下的花瓣开裂研究[J]. 船舶力学,2004,8(5):113-119.ZHANG Z H,ZHU X. Petaling of rigid plastic plate under contact explosive loading of cylindrical dynamite [J]. Journal of Ship Mechanics,2004,8(5):113-119. 盖京波,王善,杨世全. 舰船板架在接触爆炸冲击载荷作用下的破坏[J]. 舰船科学技术,2005,27(5):16-18.GAI J B,WANG S,YANG S Q. Damage of naval panels subjected to contact explosion loading[J]. Ship Science and Technology,2005,27(5):16-18. 徐定海,王善,杨世全. 板壳结构接触爆炸数值仿真分析[J]. 哈尔滨工程大学学报,2006,27(1):53-56.XU D H,WANG S,YANG S Q. Numerical simulation analysis of contiguous explosion for plate-shell structure[J]. Journal of Harbin Engineering University,2006,27(1):53-56. 张婧. 接触爆炸载荷作用下舰船板壳结构破坏分析[D]. 哈尔滨:哈尔滨工程大学,2007. 施兴华,张婧,王善. 接触爆炸载荷作用下单层薄板临界破坏分析[J]. 南京理工大学学报:自然科学版,2009,33(2):238-241.SHI X H,ZHANG J,WANG S. Critical damage of thin plate under contact explosion loading[J]. Journal of Nanjing University of Science and Technology(Nature Science),2009,33(2):238-241. 王佳颖,张世联,徐敏. 接触爆炸下舰船强力甲板塑性动态响应特性研究[J]. 中国舰船研究,2010,5(5):10-14,21.WANG J Y,ZHANG S L,XU M. Plastic dynamic response characteristics of warship’s strength deck under contact explosion[J]. Chinese Journal of Ship Research,2010,5(5):1014,-21. 吉田隆. 旧海军舰船の爆弹被害损伤例につぃて (1)[J]. 船の科学,1990(5):69-73. -
