Vibration Wave Propagation Characteristics Optimization Analysis ofthe Typical Pedestal on Double Cylindrical Shell
-
摘要: 采用波动分析法，根据不均质结构中的阻抗特性和波型转换，分析振动噪声在典型双层壳结构中的传递特性。以此为切入点，采用有限元/边界元（FEM/BEM）耦合法分析人为构造的传递损失基座的减振降噪性能。通过对组合板振动波的传递特性的分析可以得出，当定常结构发生突变时，结构阻抗也会随之发生变化，导致结构之间的阻抗失配，从而使得振动波在突变截面处发生反射和透射，降低振动波的传递效率，阻隔振动波能量向下游结构传递。然后，据此理论设计了传递损失基座，并用有限元/边界元耦合法验证了传递损失基座的减振降噪性能。Abstract: According to impedance mismatch and wave mode conversion in heterogeneous structure which based on wave analysis method，the characteristics of vibration wave propagation in typical submarine structure were studied. Based on this，vibration and noise reduction performance of artificial transmission loss base was analyzed through FEM/BEM coupled method. By reviewing vibration wave transmission characteristics for composite plate，the conclusions are drawn that the structure impedance changes，when the structure cross section mutates. Thus，leading to impedance mismatch between the structures，so the vibration wave will reflect and transmit in the mutant cross-section，and reduce the transmission rate of vibration. An artificially constructed transmission loss base was designed using the theory，and the vibration and noise reduction performance of the base was verified by FEM / BEM coupled method.
-
Key words:
- wave theory /
- wave converter /
- impedance mismatch /
- finite element /
- boundary element /
- ship
-
阿·斯·尼基福罗夫. 船体结构声学设计[M]. 谢信， 王轲，译. 北京：国防工业出版社，1998. 姚熊亮，计方，钱德进，等. 典型船舶结构中振动波传 递特性研究[J]. 振动与冲击，2009，28（8）：20-24. CREMER L，HECKL M，UNGAR E E.Structure-borne sound，second edition[M]. Berlin：Springer-Verlag， 1988. 诺顿M P. 工程噪声和振动分析基础[M]. 盛元生， 顾伟豪，韩建民，译. 北京：航空工业出版社，1993. 石勇，朱锡，刘润泉. 方钢隔振结构对结构噪声隔离 作用的理论分析与试验[J]. 中国造船，2004，45（2）： 36-42. SHI Y，ZHU X，LIU R Q.Analysis and experimental research on the role of quadrate steel beam in isolating vibration wave[J]. Ship Building of China，2004，45（2）： 36-42. PETERSSON B，PLUNT I.Approximate effective point mobilities for foundations and machinery footing[C]/ Internoise-81，Proceeding，1981：128-132. GRICE R M，PINNIGTON R J. A method for the vibration analysis of built-up structures，Part I：introduction and analytical analysis o f the plate-stiffened beam [J]. Journal of Sound and Vibration，2000，230（4）： 825-849. 刘见华. 舰船结构声传递的阻抑机理及应用研究 [D]. 上海：上海交通大学，2003. LIU J H.Study on the impending mechanism and application of the warship structure-borne sound propagation[D]. Shanghai：Shanghai Jiao Tong University， 2003. PARK D H，HONG S Y，KIL H G，et al. Power flow models and analysis of in-plan waves in finite coupled thin plates[J]. Journal of Sound and Vibration，2001， 244（4）：651-668. 赵松龄. 噪声的降级与隔离[M]. 上海：同济大学出 版社，1985. MACE B R，MANCONI E.Modelling wave propagation in two-dimensional structures using finite element analysis[J]. Journal of Sound and Vibration， 2008，318（4/5）：884-902. ICHCHOU M N，AKROUT S，MENCIK J M.Guided waves group and energy velocities via finite elements [J]. Journal of Sound and Vibration，2007（305）： 931-944. -
